9 TECHNICAL DATA

Overall capacity – Litre (quarts)
Type
Category
Annual Energy Consumption (KWh/annum)
Climate Class
Energy Efficiency Index (EEI)
Connection voltage (except North America)
Connection voltage North America
Rated current
12V DC
‐
24V DC
‐
100-240 VAC
‐
120 VAC
‐
Cooling Capacity
Ambient Temperature
Weight – Nett - Kg (lb)
Noise (dbA)
Refrigerant - R134a – g (oz)
External Dimensions – mm (in) – Figure 17a
H1
‐
W1
‐
D1
‐
Internal Dimensions – mm (in) – Figure 17b
H2
‐
H3
‐
W2
‐
D2
‐
D3
‐
Note: The maximum cooling capacity is 50°C (122°F) below ambient
temperature. If the ambient temperature is above 32° (90°F) the minimum
temperature cannot be achieved.
Figure 17a
This device is CFC-free. The coolant circuit contains R134a. Removal or recharge of
refrigerant should only be done by an authorised refrigeration mechanic.
23
60 (63)
10800050
1
90
N,T
A+
12/24 V DC and 100-240 V AC
12/24 V DC and 120V AC ~ 60Hz
6.8 A
3.4 A
1.0 – 0.5 A
1.0 A
+ 10 °C to –18 °C (+50 °F to 0 °F)
+16°C to +43°C (+70 °F to +109°F)
32 (70)
50
58 (2.0)
435 (17.3)
490 (19.3)
820 (32.3)
332 (13.1)
144 (5.7)
355 (14.0)
477 (18.8)
633 (24.9)
Figure 17b
