Type 3232, 3233, 3233 K, 3234,

Structure and Function

7. sTrucTure and funcTiOn
7.1.

structure

The manually actuated diaphragm valve consists of a manual actuator
and a 2/2-way valve housing.
7.2. Type description
The types differ in the housing.
7.2.1. Type 3232, 3233 and 3233 K
Fig. 3: Example of the 2/2-way valve type 3232, 3233 and
3233 K
Q-Pulse Id VM422
3235, 3239
Handwheel with position indi-
cator (see chapter 7.3.1)
Attachment
Diaphragm housing
Port connection
7.2.2. Types 3234, 3235 and 3239
type
T-Valve T-Valve
Type 3234 housing
Tank bottom Tank bottom
valve valve with
Type 3235 welding flange
Y-Valve Y-Valve
Type 3239 housing
Tab. 7: Structure. Types 3234, 3235 and 3239
