Materials
Approvals
Suitable for foodstuffs
• The composition of the EPDM and PTFE/EPDM diaphragms corresponds to the Code of Federal Regulations,
published by the FDA (Food and Drug Administration, USA).
Medium temperature
Pressure-temperature compatibility chart
DN 15-50
10
8
6
PVC
4
2
20 40
Q-Pulse Id VM422
3232
PVDF
PP
60
80 100 120 140
temperature [°C]
PPS
PPS
EPDM or
PTFE/EPDM
PVC-U,
PP or
PVDF
