General Technical Data - bürkert 3232 Bedienungsanleitung

Goodnal STP ST041 General (Buerkert Fluid Control Systems Type 3232 Smart Systems Manual) Vendor Manual
maximum permitted medium pressure
The values are valid for housing made of:
• VA pipe reshape housing with welded support (DIN 11850 series 2)
nominal max. switchable medium pressure [bar]
width
handwheel and attachment
dn
pps
[mm]
epdm/fkm
4/6/8/10 10
15 10
20 10
25 10
32 10
40 10
50 10
Tab. 5: Maximum permitted medium pressure
maximum permitted medium pressure
nominal width max. switchable medium pressure [bar]
dn
handwheel and attachment gray cast iron anodized
[mm]
epdm / fkm
65 5
80 5
100 5
Tab. 6: Maximum permitted medium pressure
Q-Pulse Id VM422
10
handwheel pps /
attachment stainless steel
ptfe epdm/fkm ptfe
10 10
10 10
10 10
10 10
10 10
10 10
10 10
ptfe
5
5
5
english
6.3. general technical data
materials
Housing
Actuator
10
10
10
Diaphragm
10
10 connections
10
Medium connection
10
media
Flow media
installation position
Active 29/10/2013
Type 3 232, 3233, 3233 K, 3234,
3235, 3239
Technical data
Pipe reshape housing (VA), Precision casting
(VG), Forged steel (VS), PP, PVC, PVDF
Handwheel and attachment PPS
Handwheel PPS and attachment stainless
steel
Handwheel and attachment stainless steel
Handwheel and attachment gray cast iron
epoxy coated DN 65 to DN 100
EPDM, PTFE, FKM
Welded connection according to DIN EN
1127 (ISO 4200), DIN 11850 series 2
other connections on request
Type 3232; contaminated, aggressive,
ultrapure, sterile media and media with higher
viscosity
In any position, floor drain valve type 3235;
actuator face down
Page 19 of 76
