Operating Conditions; General Technical Data; Mechanical Data - bürkert 8835 Matrix Bedienungsanleitung

6.4

Operating conditions

WARNING!
Risk of injury
Malfunction if used outside.
▶ Do not use the device outdoors.
▶ Avoid heat sources which may cause the allowable temperature
range to be exceeded.
Ambient temperature: –30 ... +80 °C
Medium temperature: –30 ... +100 °C
Medium pressure: –0.35 ... 3.0 bar
Viscosity: max. 40 mm²/s
Flow media: Water, alcohol, oil, steam
Degree of protection: IP65 according to EN 60529
(only if cables, plugs and sockets
have been connected correctly)
8
english
Type 8835
Technicaldata
6.5

General technical data

6.5.1 Mechanical data

220
50
207
Fig. 1: Dimensions single matrix
50
86,5
