• Do not use this saw to cut fire wood.
• The machine is equipped with a safety switch to
prevent it being switched on again accidentally af-
ter a power failure.
• Before you use the machine for the first time,
check that the voltage marked on the rating plate
is the same as your mains voltage.
• If you use a cable reel, the complete cable has to
be pulled off the reel.
• Persons working on the machine should not be
distracted.
• Note the direction of rotation of the motor and
blade.
• Never dismantle the machineʼs safety devices or
put them out of operation.
• Never cut workpieces which are too small to hold
securely in your hand.
• Never remove loose splinters, chips or jammed
pieces of wood when the saw blade is running.
• It is imperative to observe the accident prevention
regulations in force in your area as well as all other
generally recognized rules of safety.
• Note the information published by your profession-
al associations.
• Adjustable protective devices have to be adjusted
as close as possible to the workpiece.
• Important! Support long workpieces (e.g. with a
roller table) to prevent them sagging at the end
of a cut.
• Make sure the blade guard (3) is in its lower posi-
tion when the saw is being transported.
• Safety guards are not to be used to move or mis-
use the machine.
• Blades that are misshapen or damaged in any way
must not be used.
• If the table insert is worn, replace it.
• Never operate the machine if either the door pro-
tecting the blade or the detachable safety device
are open.
• Ensure that the choice of blade and the selected
speed are suitable for the material to be cut.
• Do not begin cleaning the blade until it has come
to a complete standstill.
• For straight cuts of small workpieces against the
longitudinal limit stop the push stick has to be
used.
• The bandsaw blade guard should be in its lowest
position close to the bench during transport.
• For miter cuts when the table is tilted, the paral-
lel stop must be positioned on the lower part of
the table.
• When cutting round timber, use a suitable holding
device to prevent the workpiece turning.
• Never use guards to lift or transport items.
• Ensure that the bandsaw blade guards are used
and correctly adjusted.
26 | GB
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
• Keep your hands a safety distance away from the
bandsaw blade. Use a push stick for narrow cuts.
• The push stick has to be stored on the intended de-
vice, so that it can be reached from normal working
position and is always ready to be used.
• In the normal operating position the operator is in
front of the machine.

6. Technical data

Electro motor
Power
Revolutions
Saw band length
Saw band width
Saw band width max.
Cutting speed
Passage height
Passage width
Table size
Slewing range of the table
Max. size of the workpiece
Overall size
Weight
The work piece must have a minimum height of 3mm
and a minimum width of 10 mm.
The total noise values determined in accordance
with EN 61029.
sound pressure level L
pA
uncertainty K
pA
sound power level L
WA
uncertainty K
WA
Wear hearing protection.
The effects of noise can cause a loss of hearing.
Total vibration values (vector sum - three directions)
determined in accordance with EN 61029.

7. Remaining hazards

The machine has been built using modern technolo-
gy in accordance with recognized safety rules. Some
remaining hazards, however, may still exist.
• Risk of injury for fingers and hands by the rotating
saw band due to improper handling of the work
piece.
• Risk of injury through the hurling work piece due
to improper handling, such as working without the
push stick.
220 - 240 V ~, 50 Hz
750 W
1400 min
-1
2240 mm
12,5 mm
15 mm
720 m/min
360 m/min
0 - 175 mm
305 mm
500 x 400 mm
0° to 45°
600 x 600 x 175 mm
74 kg
77,4 dB(A)
3 dB
90,4 dB(A)
3 dB
