Brainlab BUZZ Technisches Planungshandbuch Seite 51

PLANUNG
Buzz in-wall Dual Display - Grundriss
Beispiel-Grundriss für Buzz in-wall Dual Display:
EQUIPMENT ROOM/
TECHNICAL ROOM
(ADJACENT TO OPERATING ROOM
[ALTERNATIVE LOCATION CAN BE
CONSIDERED OUTSIDE PATIENT
ENVIRONMENT. TO BE DISCUSSED
AT PLANNING STAGE]
2xTRANSFER LINE
BOXES TRANSMITTER
BUZZ
WORKSTATION
COMPUTER RACK
CABLE DUCT
RECOMMENDED
BRAINLAB COMPONENTS
3RD PARTY COMPONENTS
COSTUMER INSTALLATION
HINWEIS: Beachten Sie bei der Planung, dass die Kupferkabelverbindungen zwischen der
Übertragungsstrecke und dem Display eine andere Länge haben (4 m) als die
Kupferkabelverbindungen zwischen der Übertragungsstrecke und der Workstation (ca. 1,8 m).
Technisches Planungshandbuch Aufl. 1.3 Buzz Version 1.0
CSU ANESTHESIA
MAX. TOTAL CABLE
LENGTH: 4M
MAIN
SWITCH
REQUIRED
1.01
MAX. TOTAL
CABLE BUZZ 42" TOUCH
LENGTH: 50m
DISPLAY IN-WALL
1.02
TRANSFER LINE BOX
MAIN SWITCH REQUIRED
RECEIVER
OR TABLE
BUZZ 42" TOUCH
MAX. TOTAL
CABLE
DISPLAY IN-WALL
LENGTH: 50m
TRANSFER LINE BOX
RECEIVER
MAX. TOTAL CABLE
LENGTH: 4m
MAX. TOTAL CABLE LENGTH: 50m
NURSE STATION
(i.e. Imaging target)
ELECTRICAL ONSITE PREPARATION
SYMBOL DESCRIPTION
CONDUITS WITH PULL WIRE
BLANKPLATE FOR CABLE FEED THROUGH
POWER SWITCH, INSTALLATION ACCORDING TO NATIONAL
GUIDELINES
STANDARD POWER OUTLET - ACCORDING TO LOCAL NORMS,
RECOMMENDED GENERATOR AND UPS BACKED UP
RJ45 NETWORK SOCKET (HOSPITAL NETWORK)
POTENTIAL EQUALIZATION (OPTIONAL)
OPERATING ROOM
OR LIGHT
VIDEO EXTENSION UNIT
FOR BUZZ
CSU SURGERY
Abbildung 27
PATIENT ENVIRONMENT
LAMINAR AIRFLOW
FIELD
OR LIGHT
51
