PLANUNG
Buzz on-wall flexible - Kabeldiagramm
Beispiel-Kabeldiagramm für Buzz on-wall flexible:
Operating
Room
RGB/
VGA In
Technisches Planungshandbuch Aufl. 1.3 Buzz Version 1.0
Hospital
network
1x S-Video (PAL / NTSC)
1x Composite (PAL / NTSC)
2x SDI
(Various resolutions)
Endoscope
SDI Room
or AUX DVI
Camera
or AUX SDI
Legend:
Power Cable (AC)
Power Cable (DC)
Fiber-Optic Cable
DVI/HDMI Cable
Other Video Cable
Other Cable
Button Link Cable
USB Cable
2D C-Arm
Microscope or
or
AUX Composite Ultrasound
or
AUX S-Video
USB E/O
USB
Converter
HDMI E/O
HDMI
Converter
RS232
RS
232
Converter
Abbildung 21
