Buzz In-Wall - Brainlab BUZZ Technisches Planungshandbuch

Standard-Layouts und Kabelkonzepte
3.2.3

Buzz in-wall

Buzz in-wall - STC-Diagramm
Beispiel-STC-Diagramm für Buzz in-wall:
Operating
Room
8 m
2x 4 LC (DVI)
2x ST (RS232)
FO lines and converters
4xLC;4xLC; 2xST
must be ordered
seperately
4xLC
Video Extension
Unit (NDS Box)
2x S-Video (PAL / NTSC)
2x Composite (PAL / NTSC)
2x SDI (1920 x 1080)
SDI Room
AUX
Endoscope
Camera
RGB
or AUX DVI
or AUX SDI
48
50 m
6x fiber optic cable
control
backward channel: refer to specifications
video signals
4xLC
6xLC, 2xSC
Touchscreen (In-Wall)
Microscope or
2D C-Arm
Ultrasound
or
or
AUX Composite
AUX S-Video
Equipment Room
8x fiber optic cable
50m 6xLC, 2xSC
TL-Box II
Clones of
Touch
Screen 1
Legend:
Power Cable (AC)
Power Cable (DC)
Fiber-Optic Cable
DVI/HDMI Cable
Other Video Cable
Other Cable
Button Link Cable
USB Cable
Abbildung 24
Technisches Planungshandbuch Aufl. 1.3 Buzz Version 1.0
Control /
Hospital
network
2x ST
8x LC
2x Spare
Work
TL-Box I
Station
4x copper cables
(ca.1.8 m)
HDMI HDMI
DVI (1920 x 1080)
FO lines and converters
must be ordered
seperately
DVI (1920 x 1080)
USB E/O
USB
Converter
HDMI E/O
HDMI
Converter
RS232
RS
232
Converter
