Brainlab BUZZ Technisches Planungshandbuch Seite 50

Standard-Layouts und Kabelkonzepte
Buzz in-wall Dual Display - Kabeldiagramm
Beispiel-Kabeldiagramm für Buzz in-wall Dual Display:
Equipment Room
Buzz PC
Hospital
LAN
Transfer
Lines
Wiring diagram in one OR
50
OR
8x optic fiber
Transfer Line
Video Extension Unit
Transfer Line
Transfer
Lines
Connection
point
DVI Video Source SDI-Video Source
(e.g. Microscope)
(e.g. Endoscope)
Brainlab
Brainlab partner
e.g. Crestron
8x optic fiber
Transfer Line
Room Camera
Video Signal of
OR Light Camera
Composite Video Source
VGA Video Source
S-Video Source
(e.g. C-Arm)
(e.g. Vital Monitoring)
(e.g. Ultrasound)
Legend:
Power Cable (AC)
Power Cable (DC)
Fiber-Optic Cable
DVI/HDMI Cable
Other Video Cable
Other Cable
Button Link Cable
USB Cable
Abbildung 26
Technisches Planungshandbuch Aufl. 1.3 Buzz Version 1.0
Transfer Line
Buzz – In-Wall Version dual display
Additional Displays
(up to 3)
USB E/O
USB
Converter
HDMI E/O
HDMI
Converter
RS232
RS
232
Converter
