76/110 Bosch Rexroth AG

About this product

4 About this product
4.1

Components in figures

Components in figures are numbered ac-
cording to the representation of the hand-
held nutrunners on the graphical pages.
1 Tool mount (external square) with safety
pin
2 Output drive (e.g. angle head)
3 Flange of the output drive
4 Union nut
5 Start switch
6 Status bar
7 Tool button
8 CW/CCW reversal switch ESA/ ESV/
CC-ESA/ CC-ESV
9 CW/CCW reversal switch ESM/
CC-ESM
10 Handle
11 Electric connection
12 Tightening position illumination
13 Adapters for handling devices
14 Rexroth tightening system interface
15 ErgoSpin connecting cable
16 Rotatable angle plug
17 Attachment tools (e.g. socket)
18 Safety pin
19 Quick-change chuck sliding collar
20 Assembly aid
21 Hook wrench
Some of the accessories illustrated or de-
scribed are not included in the scope of de-
livery.
ErgoSpin/CC-ErgoSpin | 3608870DD4/2015-09
5

Transport and storage

For storing and transporting the product, al-
ways observe the ambient conditions speci-
fied in the technical data of this product. In-
formation on the technical data is contained
in the corresponding section of these instruc-
tions.
