Eingabe Motor-Bestell-
in P096 nummer (MLFB)
57 1FT6105-1AC7_-1A
1FT6105-8AC7_
58 1FT6105-8AF7_
59 1FT6105-8SB7_
60 1FT6105-8SC7_
61 1FT6105-8SF7_
62 1FT6108-8AB7_
63 1FT6108-8AC7_
64 1FT6108-8SB7_
65 1FT6108-8SC7_
66 1FT6132-6AB7_
67 1FT6132-6AC7_
68 1FT6132-6AF7_
69 1FT6132-6SB7_
70 1FT6132-6SC7_
71 1FT6132-6SF7_
72 1FT6134-6AB7_
73 1FT6134-6AC7_
74 1FT6134-6SB7_
75 1FT6134-6SC7_
76 1FT6134-6SF7_
77 1FT6136-6AB7_
78 1FT6136-6AC7_
79 1FT6136-6SB7_
80 1FT6136-6SC7_
81 1FT6108-8SF7_
High Dynamic
82 1FK6033-7AK71
1FK7033-7AK71
83 1FK6043-7AK71
1FK7043-7AK71
84 1FK6043-7AH71
1FK7043-7AH71
85 1FK6044-7AF71
1FK7044-7AF71
86 1FK6044-7AH71
1FK7044-7AH71
87 1FK6061-7AF71
1FK7061-7AF71
Siemens Controls
6SE7087-6JD50
Betriebsanleitung
manuals search engine
Drehzahl Drehmoment
n [1/min] M [Nm]
n n
2000 38,0
3000 31,0
1500 59,0
2000 56,0
3000 50,0
1500 61,0
2000 55,0
1500 83,0
2000 80,0
1500 62,0
2000 55,0
3000 36,0
1500 102,0
2000 98,0
3000 90,0
1500 75,0
2000 65,0
1500 130,0
2000 125,0
3000 110,0
1500 88,0
2000 74,0
1500 160,0
2000 150,0
3000 70,0
6000 0,9
6000 2,0
4500 2,6
3000 3,5
4500 3,0
3000 5,4
Parametrierung
Strom Polpaar-
I [A] zahl
n
17,6 4
22,5 4
21,7 4
28,0 4
35,0 4
20,5 4
24,5 4
31,0 4
40,0 4
19,0 3
23,0 3
23,0 3
36,0 3
46,0 3
62,0 3
24,0 3
27,0 3
45,0 3
57,0 3
72,0 3
27,0 3
30,0 3
55,0 3
72,0 3
53,0 4
1,5 3
4,4 3
4,0 3
4,0 3
4,9 3
5,3 3
