Number / Alarm
A183
Block no. of block
search fwd l. 0 does
not exist
A184
Block no. of block
search forward is no
UP call
A185
Block no. of block
search forward does
not exist
A186
Block no of block
search fwd lev 1 is no
SP call
A187
Block no of block
search fwd lev 2 does
not exist
A188
Rem. loop count bl.
search fwd lev1/2 not
allowed
A190
Digital input not
programmed
A191
Digital input not
actuated
Siemens AG
SIMOVERT MASTERDRIVES
Downloaded from www.Manualslib.com
Cause
The block number for the main program (level
0), which was transferred with block search,
does not exist in the main program.
Effect:
NC program execution is inhibited.
The block number for the main program (level
0), which was transferred with block search,
does not contain a subprogram call for
subprogram level 1.
Effect:
NC program execution is inhibited.
The block number for subprogram level 1,
which was transferred with block search, does
not exist in the subprogram.
Effect:
NC program execution is inhibited.
The block number for subprogram level 1,
which was transferred with block search, does
not contain a subprogram call for subprogram
level 2.
Effect:
NC program execution is inhibited.
The block number for subprogram level 2,
which was transferred with block search, does
not exist in the subprogram.
Effect:
NC program execution is inhibited.
The remaining loop count transferred with
block search for subprogram level 1 or 2 is
greater than the programmed loop count.
Effect:
NC program execution is inhibited.
The NC block which was read in contains the
"inprocess measurement" or "set actual value
on-the-fly" function, although a digital input
has not been programmed for this function
(machine data 45).
Effect:
NC program execution is inhibited or aborted,
the axis is brought to a standstill via the
deceleration ramp.
Although the "external block change" function
was programmed, the digital input was not
actuated in order to trigger the external block
change.
Effect:
The NC program is interrupted, the axis is
brought to a standstill via the deceleration
ramp.
Siemens Controls
6SE7087-6JD50
Operating Instructions
manuals search engine
Faults and Alarms
Counter-measure
For the block search function, an existing
block number must be specified as the block
number for the main program.
For the block search function, a block number
with a subprogram call must be specified as
the block number for the main program (level
0) if a block search is to be performed in
subprogram level 1.
For the block search function, a block number
which exists in this subprogram must be
specified as the block number for subprogram
level 1.
For the block search function, a block number
with a subprogram call must be specified as
the block number for subprogram level 1 if a
block search is to be performed in subprogram
level 2.
For the block search function, a block number
which exists in this subprogram must be
specified as the block number for subprogram
level 2.
For the block search function, it is only allowed
to specify a remaining loop count between 0
and the programmed loop count-1.
Program the digital input for the desired
function.
-Correct the program.
-Check the actuation of the digital input.
12-27
