11_REMOVING THE BICYCLE

- Shift the bicycle chain on the smallest cassette sprocket
of Turno and of the smallest front chainring of the bicycle.
- Open up the quick release (or remove the
thru-axle) and remove the bicycle from the Turno.
- For transportation, or simply to reduce clutter when not
in use: push the safety lever (Pic. 23) and fold the front
leg (Pic. 24).
- It's also possible to rotate the front foot by 60° (Pic. 25)
to fold the hometrainer more compactly after training. In
this case, the hometrainer must be stored horizontally
as indicated (Pic. 26) to prevent it falling and becoming
damaged.
12_INSTALLATION
9/10/11 SPEED COMPATIBLE CASSETTE
FREEHUB BODY
- To replace the original freehub body installed on Turno
with the accessory body compatible with Campagnolo
9/10/11 speed cassettes, follow the procedure below:
1) Unscrew the adapter on the cogset shaft (Pic. 27).
2) Remove the freehub body from the Turno shaft (Pic. 28).
3) Fully insert the Campagnolo
freehub body (Pic. 29-30).
4) Tighten the cog set shaft adapter using a 5 mm hex
wrench to a torque of 5 Nm (44in-lbs). Use a medium-
strength oil tolerant threadlocker to lock the adapter on the
shaft.
- 2 spacers (Ref. B) are usually needed for the
Campagnolo 9 speed cassette (Pic. 7), 1 spacer for the
®
10 speed cassette (Pic. 7A) and no spacer is required for
the 11 speed cassette (Pic. 8). Depending on the cassette
brand you are using there might be some differences with
the aforementioned general data.
ATTENTION!
Strictly follow the instructions provided by the cassette
manufacturer with regard to specific installation techniques,
the need for additional spacers and torque specifications.
NOTE: please contact your dealer if you have questions
about installation or if you cannot install the cassette. The
warranty does not cover any damage to the bicycle and/or
Turno in the event of incorrect installation.

13_MAINTENANCE

Turno does not require any specific scheduled maintenance,
however the following precautions are recommended:
- wipe the trainer clean with a cloth after each training
session to prevent the accumulation of dust and sweat;
- do not clean or degrease the bicycle chain while the bike
is mounted on Turno as solvents can cause irreparable
damage to the bearings or other internal mechanical parts;
OF CAMPAGNOLO
cassette compatible
®
- check that the quick release is properly secured and fully
working before every training session;
- The tension of the internal transmission belt is calibrated
and checked on each product in the assembly line; such
tension might however diminish after prolonged use or a
particularly strenuous session, thus creating an imperfect
force transmission to the resistance system. If that's the
case, increase tension on the transmission belt by doing
as follows:
1) Unscrew the regulator screw-lock by one turn so you can
work on the regulator (Pic. 32).
2) Turn the adjusting nut half a turn to tighten the belt
correctly (Pic. 33).
3) Tighten the adjustment locking screw (under point 1) by
one full turn to set the adjustment.
®
4) if the belt is still uneven after performing this operation,
repeat step 2) and retest.

14_WARNINGS

®
- Turno becomes hot during use. Wait for it to cool before
touching the resistance unit covers.
- Use the Turno trainer as described in the manual.
- Turno is not equipped with an emergency brake.
- Turno has been designed and manufactured to ensure
maximum safety of the user and/or third parties, but
people, children and pets should be kept away from the
trainer during use as contact with the moving parts of the
trainer and the bicycle may result in damage or injury.
- Never put your fingers or foreign objects of any kind
through the slots on Turno, as there will be high risk of
damage to the trainer and/or serious physical injury.
- Before you start training, place the trainer in a suitable
location, away from any potentially dangerous objects
(furniture, tables, chairs...) so as to avoid any risk of
accidental or inadvertent contact.
- The Turno is to be used by only single rider at a time.
- Always check the safety and stability of the bicycle on
Turno before training.
- No part of the product has any use beyond its original
application. The warranty will be void if the unit has been
opened or tampered with.
- Since the feet are made of soft non-slip material, they
may leave traces of rubber on the floor during use.
- The roller is not waterproof. Please be careful of sweat
and do not use abrasive cleaners, as both may damage the
electronic circuitry.
- Do not store the Turno in cold and damp places. This
may damage its electronic components.

15_TROUBLESHOOTING

If the app is displaying incorrect data, try to re-set the
