6 Putting into operation
NOTICE
• Ensure that the non-return valve (6) is pre-attached to the suction connection (10).

6.1 Compressed air connection

1
Compressed air connector with
diam. 10
Fig. 8
Compressed air connection
1 Connect the device via the compressed air hose.
The operating pressure should be 6 bar.
If the compressed air supply is under 6 bar, the cutting capacity of the wire cutter and the speed of the
pneumatic motor will be reduced.
This will in turn reduce the performance of the torch cleaning station.
NOTICE
• We recommend operating the device with cleaned and oiled compressed air.
• An appropriate maintenance unit (2) is available as an accessory.
nom.
2
Maintenance unit
TCS-Compact
1
2
