3 Product description
3.2 Abbreviations
TCS-Compact
DAV
TCP
Tab. 9
Unit of measurement in drawings or diagrams
Tab. 10
3.3 Nameplate
The TCS-Compact cleaning station is labeled with a nameplate as follows:
Fig. 3
When making inquiries, please note the following information:
• Device type, device number, ID number, year of construction, sensor type
Abbreviations and term definitions
Dimensions
Nameplate of the TCS-Compact cleaning station
Cleaning station
Wire cutting device
Tool center point
Millimeters [mm]
TCS-Compact
