Abicor Binzel TCS-Compact Betriebsanleitung Seite 44

3 Product description
2
4
1 Cleaning unit
2 Collecting tray
Fig. 2 Technical data—version with short assembly stand
Ambient temperature
Relative humidity
Tab. 1
Ambient conditions during operation
Storage in a closed environment, ambient temperature
Ambient temperature for shipment
Relative humidity
Tab. 2 Ambient conditions for transport and storage
370
260
110
60
ø 12
(4x)
3 Bottle holder for anti-spatter fluid
1
136
168
4 Stand with flange plate
+5°C to 50°C
Up to 90% at 20°C
+5°C to 50°C
-10°C to +55°C
Up to 90% at 20°C
TCS-Compact
2
3
