4. ADJUSTMENT ITEMS

[A] Initial Settings
[B] Adjustment of SW. REG.
1. Adjustment method
[C] Pre-Adjustment
1. High-Voltage Adjustment
[D] Main Adjustment
1. Screen Voltage Adjustment
2. Horizontal Raster Position
3. Deflection Distortion Adjustment
3-1. Horizontal / Vertical Size Rough Adjustment
3-2. Picture Tilt Adjustment
3-3. Parallelogram Distortion Adjustment
3-4. Trapezoid distortion Adjustment
3-5. Side Pincushion Balance Adjustment
3-6. Side Pincushion Adjustment
3-7. Distortion Adjustment
4. Preset Picture Size and Position Adjustment
5. Video Amplitude Adjustment
5-1. Gain Adjustment
5-2. Cut Off Adjustment
5-3. Brightness Max Adjustment
5-4. Color Temperature Adjustment
5-5. Brightness Adjustment
6. Focus Adjustment
7. CRT Convergence
8. OSD setting
[E] Reference
1. Adjustment Signal
2. Timing of Adjustment Signals
3. Position of Connector / Test point of Adjustment and Inspection
