NEC MultiSync FE700 Serviceanleitung Seite 174

SYMBOL PART NO
D3A2 79PQ0065
D4A1 79PQ0065
D4A2 79PQ0065
D601 79PQ0065
D602 79PQ0065
D604 79PQ0065
D605 79PQ0065
D701 79PQ0065
D704 79PQ0065
ZD101 79PQ0078
ZD102 79PQ0077
ZD103 79PQ0078
ZD104 79PQ1441
ZD105 79PQ1252
ZD301 79PQ0077
ZD303 79PQ0075
ZD701 79PQ0292
ZD702 79PQ0292
ZD703 79PQ0292
ZD704 79PQ0292
ZD706 79PQ0292
*** TRANSFORMERS ***
T101 79PQ1440
T301 79PQ1361
T302 79PQ0030
T303 79PQ1240
*** VARIABLE RESISTORS ***
VR101 79PQ0195
VR102 79PQ0194
VR302 79PQ0195
VR307 79PQ1076
*** RELAYS & SWITCHES ***
SW101 79PQ0974
SW701 79PQ1437
SW702 79PQ1437
SW703 79PQ1437
SW704 79PQ1437
SW705 79PQ1437
SW706 79PQ1437
SW707 79PQ1437
*** PWB ASSYS ***
849E9B01
849E9F01
849E9J01
DESCRIPTION
DIODE T" 1N4148"
DIODE T" 1N4148"
DIODE T" 1N4148"
DIODE T" 1N4148"
DIODE T" 1N4148"
DIODE T" 1N4148"
DIODE T" 1N4148"
DIODE T" 1N4148"
DIODE T" 1N4148"
ZEN DIODE 1/2W(T) 18V
ZEN DIODE 1/2W(T) 12A2
ZEN DIODE 1/2W(T) 18V
ZEN DIODE 1/2W(T) HZS6B2
ZEN DIODE 1/2W(T) HZS20.2
ZEN DIODE 1/2W(T) 12A2
ZEN DIODE 1/2W(T) 5C2
ZEN DIODE 1/2W(T) 6C2
ZEN DIODE 1/2W(T) 6C2
ZEN DIODE 1/2W(T) 6C2
ZEN DIODE 1/2W(T) 6C2
ZEN DIODE 1/2W(T) 6C2
POWER X'FM ERL35 500UH(3.
17FBT DOUBLE FOCUS"
H.DRIVE X'FM 4.5MH EI-19
TRANS, H.DF X'FM EI-19
VR CARBON 6MM10K VZ067TL1
VR CARBON 6MM 1K
VR CARBON 6MM10K VZ067TL1
VR CARBON 6MM 200K BM
POWER SW ESB92S21B TV5
TACT SW SKHHQV
TACT SW SKHHQV
TACT SW SKHHQV
TACT SW SKHHQV
TACT SW SKHHQV
TACT SW SKHHQV
TACT SW SKHHQV
SUB PWB ASSY
MAIN PWB ASSY
CRT PWB ASSY
