Adjustment / Inspection Signal（9）
PROGRAM NO.
SIGNAL NAME
RESOLUTION
DOT CLOCK
fh
fv
H CELL SIZE
(A) TOTAL
(D) DISP
(E) FRONT
(B)
SYNC PULSE
(C) BACK
V CELL SIZE
(O) TOTAL
(R) DISP
(F) FRONT
(P)
SYNC PULSE
(Q) BACK
INTERLACE
POLARITY (H/V)
COMPOSITE
SYNC
COMPOSITE
VIDEO
CHARACTER
FONT
SERRATION
EQP
111
1152*864
@70Hz
1152*864
1660*1200
(MHz) 94.500
(kHz) 63.85
(Hz) 70.01
(DOT) 8
(DOT) 1480
(CHR) 185
(uS) 15.66
(DOT) 1152
(CHR) 144
(uS) 12.19
(DOT) 32
(uS) 0.34
(DOT) 96
(uS) 1.02
(DOT) 200
(uS) 2.12
(H) 16
(H) 912
(mS) 14.283
(H) 864
(CHR) 54
(mS) 13.531
(H) 1
(mS) 0.016
(H) 3
(mS) 0.047
(H) 44
(mS) 0.689
NON
POS/POS
7*9
OFF
OFF
112 113
VESA 640*480
@120Hz
1600*1200
(i)
640*480
135.000 54.000
62.50 63.68
96.15 120.61
8 8
2160 848
270 106
16.00 15.70
1600 640
200 80
11.85 11.85
48 32
0.36 0.59
192 64
1.42 1.19
320 112
2.37 2.07
16 16
650 528
10.400 8.292
600 480
37.5 30
9.600 7.538
1 2
0.016 0.031
3 4
0.048 0.063
46 42
0.736 0.660
NON
S&VIDEO
POS/POS NEG/NEG
7*9 7*9
OFF OFF
OFF OFF
5-34
114
MAC
1152*870
1152*870
100.000
68.68
75.06
8
1456
182
14.56
1152
144
11.52
32
0.32
128
1.28
144
1.44
16
915
13.322
870
54.375
12.667
3
0.044
3
0.044
39
0.568
NON
NEG/NEG
7*9
OFF
OFF
