Follow the instructions in this manual for adjustments.
(1) After adjustment finished, close menu so as to make it memorize.
(2) Turn the monitor back on and confirm that the adjustment values / picture level / white balance /
distortion values are the same before the Menu was closed.
(When "PROCEED" SW is pushed during below Menu (F) is displayed, OSM Menu disappears.
If "PROCEED" SW is pushed once more, OSM reappears. )
All TAG1 items (except DEGAUSS), All TAG2/3/4 items, MOIRE CANCELER on TAG5, BRIGHT PRESET
and CONT PRESET on TAG7.)
[A] Initial Settings
Before adjusting, set the position of control as follows.
FBT SCREEN VR :
D.FOCUS VR (F1) :
S.FOCUS VR (F2) :
VR101 (SW.REG. Adjust) :
VR102 (HV. Voltage Adjust) :
VR302 (Raster cent. Adjust :
VR307 (G1 Voltage. Adjust) :
[B] Adjustment of SW. REG .
1. Adjustment method
Signal: No. 105 (1024*768 @60Hz) All White, Size: preset size
Display all white and adjust SCREEN VR, so that the image is visible.
Adjust VR101 so that the voltage of D112 (cathode side) should be 13.6V±0.05 V.
Fully counterclockwise (MIN)
Mechanical center
Mechanical center
Fully counterclockwise (MIN)
Fully counterclockwise (MIN)
Mechanical center
Fully counterclockwise (MIN)
