NEC MultiSync FE700 Serviceanleitung Seite 89

NO Signal Name
101 USER 2
102 VESA 800*600@56Hz
103 USER 4
104 1024*768@56Hz
105 VESA 1024*768@60Hz
106 USER 7
107 800*600@80Hz
108 640*480@100Hz
109 1024*768@72Hz
110 USER 11
111 1152*864@70Hz
112 VESA 1600*1200(I)
113 640*480@120Hz
114 MAC 1152*870
※Cross hatch pattern consist of the 17 vertical lines and the 13 horizontal lines.
Video Signal
Video Signal 0.7V H/V Separate P/P
Video Signal 0.7V H/V Separate P/P
Video Signal 0.7V H/V Separate P/P
Video Signal 0.7V H/V Separate N/N
Video Signal 0.7V H/V Separate N/N
Video Signal 0.7V H/V Separate N/N
Video Signal 0.7V H/V Separate P/P
Video Signal 0.7V H/V Separate N/N
Video Signal 0.7V H/V Separate P/P
Video Signal 0.7V H/V Separate N/N
Video Signal 0.7V H/V Separate P/P
Video Signal 0.7V H/V Separate P/P
Video Signal 0.7V H/V Separate N/N
Video Signal 0.7V H/V Separate N/N
5-24
SYNC POLARITY (H/V)
