NEC MultiSync FE700 Serviceanleitung Seite 88

[E] Reference
1. Adjustment / Inspection Signal
NO Signal Name
1 VGA 350
2 VGA 400
3 VGA 480
4 640*400@70Hz
5 VESA 800*600@60Hz
6 MAC 640*480
7 VESA 350@85Hz
8 VESA 400@85Hz
9 VESA 640*480@75Hz
10 XGA
11 VESA 800*600@75Hz
12 VESA 640*480@85Hz
13 VESA 800*600@72Hz
14 MAC 832*624
15 VESA 800*600@85Hz
16 VESA 1024*768@70Hz
17 VESA 1024*768@75Hz
18 VESA 1280*1024@60Hz
19 MAC 1152*870@75Hz
20 VESA 1024*768@85Hz
28 EDID
29 VGA480(1/2)
30 31kHz/55Hz
31 1024*768@85Hz(WIN)
32 70kHz/120Hz
33 512*768@85Hz
Video Signal
Video Signal 0.7V H/V Separate P/N
Video Signal 0.7V H/V Separate N/P
Video Signal 0.7V H/V Separate N/N
Video Signal 0.7V H/V Separate N/N
Video Signal 0.7V H/V Separate P/P
Video Signal 0.7V Composite Sync Signal N/N
Video Signal 0.7V H/V Separate P/N
Video Signal 0.7V H/V Separate N/P
Video Signal 0.7V H/V Separate N/N
Video Signal 0.7V H/V Separate P/P
Video Signal 0.7V H/V Separate P/P
Video Signal 0.7V H/V Separate N/N
Video Signal 0.7V H/V Separate P/P
Video Signal 0.7V Composite Sync Signal N/N
Video Signal 0.7V H/V Separate P/P
Video Signal 0.7V H/V Separate N/N
Video Signal 0.7V H/V Separate P/P
Video Signal 0.7V H/V Separate P/P
Video Signal 0.7V Composite Sync Signal N/N
Video Signal 0.7V H/V Separate P/P
Video Signal 0.7V H/V Separate N/N
Video Signal 0.7V H/V Separate N/N
Video Signal 0.7V H/V Separate N/N
Video Signal 0.7V H/V Separate P/P
Video Signal 0.7V H/V Separate P/P
Video Signal 0.7V H/V Separate P/P
5-23
SYNC POLARITY (H/V)
