Power saving
Suspend mode
OFF mode
1) The turn on the monitor power switch when H-SYNC and V-SYNC from PC is nothing. At that time,
if the video is shifted from the free-run mode to the suspend mode, the transistor Q107 turns OFF
and the operation returns to the OFF mode within a few seconds.
2) As for the sequence of steps that turn the operation to the OFF mode, if the keyboard is not
touched for a given period of time that a preset in advance , the CPU outputs the LOW level signal
to the transistor Q107, then Q105 turns OFF, the transistor Q108 and Q104 turns OFF. As a result
the power is shut out at that state.
3) When the user touches the keyboard in the OFF mode, the operation is resumed, the video signals
V-SYNC and H-SYNC turn ON the CPU via resistor R129 and R159, then the transistor Q105 and
Q107 turn ON, the transistors Q104 and Q108 turn ON. As a result the operation returns to the ON
state.
DC/DC
The DC/DC voltage is DC 45 volts, and since the set-up voltage is variable from 62 volts to 160 volts, it
is variable depending on the horizontal synchronism. The frequency band is variable from 31 kHz to
70 kHz. The voltage is fed back from the fly-back transformer (FBT). The DC/DC output voltage is
used as high-voltage input of FBT T301.
1) DC/DC is a step-up circuit, and consists mainly of the choke L106, the transistor Q102, the diode
D114 and U102.
2) When the PWM controls U102 IC KA3843, a driving pulse is generated at the gate of the transistor
Q102, and the transistor Q102 turns ON. During the ON cycle, the energy is stored in the choke
L106. The transistor Q102 turns OFF when the driving pulse disappears from the gate of the
transistor Q102. As a result, the voltage at the dot terminal of the winding flows in the positive
direction and goes to the fly-back rectifier. The energy stored in the choke L106 is entered in the
FBT, passing through the choke L106, the diode D114 and the capacitor C129.
3) The feedback is detected by the FBT via diode D130, the capacitor C145, the resistor R145 the
variable resistor VR102 and the fixed resistor R146, and is connected to the U102-2 pin.
This loop is the regular type one
4) The frequency of the synchronization signal coming from video H-SYNC is variable from 31 kHz to
70 kHz. The circuit consists of the capacitor C132, the resistor R139, the diode D115, the resistor
R138 and the resistor R140.
5) The soft start circuit consists of the resistor R178, the capacitor C164, the diode D133 and the
diode D117.
: Every DC voltage operation of the CRT is turned OFF.
The color of the power LED101/102/103 switches from green to yellow.
: This is the mode in which the CPU control unit turns OFF the power supply, but
the power turns ON when the user touches the keyboard.
The power LED switches to orange color.
.
