Make sure that the following parts are included in the packaging of the purchased product:
•
High pressure water cleaner.
•
Hose reel complete with 10 m (CLASSIC) or 20 m (EXTRA) of high pressure delivery hose.
•
Water gun.
•
Spray gun hose.
•
Rotating spray nozzle pipe (EXTRA).
•
Foam spray nozzle.
•
Rotating high water cleaning brush with built-in detergent tank (EXTRA).
•
Wall-mounting kit complete with securing nuts, screws and wall-plugs.
•
Right and left safety hooks complete with stop rings.
•
Wall-mounted accessory frame, complete with securing screws and wall-plugs.
•
Hose reel handle.
•
Handle complete with securing screws.
•
Suction kit for use on walls, made up of gaskets, filter and quick-release fitting.
•
Suction kit for use on the ground, made up of gasket and curved hose holder fitting.
•
Instruction manual – Safety warnings.
•
Instruction manual – Use and Maintenance.
•
Guarantee certificate.
•
Service centre booklet.
•
Key for disassembling the nozzle.
•
Nozzle cleaning pin.
If there are problems, contact your dealer or an authorised assistance centre.
The following range of accessories can be added to the standard high-pressure cleaner equipment:
•
Rotating spray nozzle pipe: designed to remove stubborn dirt.
•
Sanding spray nozzle pipe: designed to sand down surfaces, to eliminate rust, paint settled dirt etc.
•
Rotating high pressure cleaning brush with built-in detergent tank: designed to clean delicate surfaces.
•
Fixed high pressure cleaning brush: designed to clean delicate surfaces.
•
Hose purging probe: designed to unclog hoses and pipelines.
•
Floor washing spray gun: designed to clean tiled floors and walls.
•
Hose cleaning-guide kit: designed to wind-up the delivery hose easily and to clean it.
•
Wheel kit: designed to make it easier to move the high pressure water cleaner around when taken off the wall.
•
10 m extension kit of the delivery hose: designed to increase the reach of the high pressure water cleaner.
•
Insert the handle and press right down (2), then secure it with the two screws supplied (37). SEE FIG. 4.
•
Insert the hose reel handle until it clicks into place (15). SEE FIG. 3.
•
Screw the high pressure hose fitting on the thread of the water gun (24) and tighten firmly with two
17-mm/0.67" fixed jaw spanners (not supplied). ILLUSTRATED IN FIG. 8.
•
Insert the filter (18) in the water inlet fitting (17). Insert the gasket (26) in the quick-release water inlet
fitting (25) and screw it on tight onto the fitting (17). SEE FIG. 1.
•
Chose a suitable wall where the high pressure water cleaner can be mounted: the high pressure water
cleaner must be mounted exclusively on brick walls or reinforced cement walls with thickness of no less
9
DOTAZIONE STANDARD
OPTIONAL ACCESSORIES
INSTALLATION – FITTING ACCESSORIES
INSTALLATION – WALL MOUNTING
