If working on the floor, exploiting a collar clip (not supplied), secure a supply hose with inside
diameter of 19 mm/0.75" to the curved water inlet hose holder.
•
Open the water supply tap, making sure there is no dripping. PROCEDURE C OF FIG. 8.
•
Make sure the main ON/OFF switch (1) is turned to "0" and connect the plug. PROCEDURE D OF FIG. 8.
•
Turn the main ON/OFF switch (1) to position "1".
•
Press the lever (22) of the high pressure water cleaner and wait for water to flow out continuously.
•
Switch the main ON/OFF switch (1) to position "0" and connect the spray hose (28) or (29) to the
water gun (24), tightening firmly. PROCEDURE E OF FIG. 8.
•
Start the high pressure water cleaner again, switching the main ON/OFF switch (1) to position "1".
NOTE: when starting in this phase, the high pressure water cleaner will stop immediately after the
starting breakaway because the TOTAL STOP device trips.
•
To activate the high pressure water cleaner, to start cleaning, simply operate the lever (22) of the
high pressure cleaning gun.
•
The angle of the jet of water can be adjusted via the head (30) (Fig. 2 - Positions a and b).
The detergents recommended by the manufacturer are over 90% biodegradable.
Refer to the label on the detergent packaging for use instruction.
•
Fill the flask (21) with the required detergent.
•
Adjust the suction capacity of the detergent as follows:
-
disconnect the device (20) from the spray nozzle (19).
-
register the tooth L of the device (20) with one of the numbers written inside the lance (19)
(1: minimum suction, 6: maximum suction).
-
fit the device (20) back in the spray nozzle (19).
•
Couple the flask (21) on the foam spray nozzle (19).
•
Switch the main ON/OFF switch (1) to position "0" and connect the spray nozzle (19) to the water gun (24).
•
Start the high pressure water cleaner again, turning the main ON/OFF switch (1) to position "1" and operate
the lever (22) (suction and mixing will occur automatically when the water flows through).
WORKING WITH DETERGENT – ROTATING BRUSH
The detergents recommended by the manufacturer are more than 90% biodegradable.
For the methods of use, refer to the information written on the label of the detergent package.
•
Raise the cap (34) and fill the tank of the rotating high pressure cleaning brush with the required detergent.
SEE FIG. 3.
•
Close the cap again (34).
•
Turn the main ON/OFF switch (1) to position "0" and connect the brush (33) to spray gun (24).
•
Start the high pressure water cleaner again, by turning the main ON/OFF switch (1) to position "1" and
operate the lever (22) (suction and mixing occur automatically once the water flows through).
•
Adjust the detergent output rate by turning the ring nut (36) accordingly.
•
Release the lever (22) of the high pressure water gun and the cleaner will stop automatically.
The cleaner will start again regularly the next time the lever of the high pressure water gun is pressed
11
STANDARD OPERATION (AT HIGH-PRESSURE)
WORKING WITH DETERGENT – FOAM SPRAY
STOPPING – TOTAL STOP
