Overview Bigrep Studio - BigRep STUDIO Betriebsanleitung

BigRep STUDIO

3.2. Overview BigRep STUDIO

A
B
C
D
E
F
z
y
x
A Filament guides (2 pcs)
B Emergency stop button (2 pcs)
C Reset button
D USB Ports (4 pcs)
E Touchscreen display
F Adjustable rollers (4 pcs)
G Extruder
H Print Bed
I X-guide rail (2 pcs)
J Service hatch (2 pcs)
K Y-guide rails
L Mobile machine base (4 pcs)
M Z-guide sha s (2 pcs)
N Z-lead spindels (4 pcs)
O Door
P Spool storage space
R Main plug
S Main switch
T Control cabinet
U LAN Port (RJ45 connector)
Construction and Function
3
J
I
H
G
Fig. 3-1: BigRep STUDIO
B
P
O
N
M
L
K
U R S T
J
