8.2 Technical data

AQWL STD/HSE/HPF - BLN models
Power supply
Number of refrigerant circuits
Refrigerant charge
Total capacity steps
COMPRESSORS
Number
Type
Oil type
N° of loading stages
EVAPORATOR
Number
Type
Water volume
AIR COOLED CONDENSER
Number of coils
Total coil face area per coil
FANS
Number of fans
Nominal speed
Total airflow
Total input power
Total input power (*)
External static pressure
WEIGHT
Shipping weight
Operating weight
ADDITIONAL WEIGHT
HSE version
HPF version
Desuperheater version
With pump/s
With pump/s and tank
Copper Fins
SOUND LEVELS
Sound power level (1)
Sound pressure level - (10m) (2)
DIMENSIONS
Length
Width
Height
(1) Sound levels are at fully loaded conditions. Sound power level values refer to ISO standard 3744 and Eurovent 8/1.
(2) Sound pressure levels refer to ISO standard 3744, parallelepiped shape.
(*) High efficiency units (HSE) with inverter fans.
(**) HPF units with high static pressure fans.
Note: Refrigerant charge data are indicative only. Always refer to data shown on the unit nameplate.
8 - Technical Data (continued)
1404
V/Ph/Hz
2
kg 40 + 40
% 21-50-71-100
4
0/100
1
PLATE
l 33
4
m² 4.4
8
rpm 880
m³/h 162000
kW 14.4
kW 13.0
Pa
kg 2633
kg 2668
kg 0
kg 0
kg
kg
kg
kg
dB(A) 97
dB(A) 65
mm 4000
mm 2200
mm 2550
1604 1806
400 (±10%)/3/50
2 2
44 + 44 52 + 52
25-50-75-100 17-33-50-67-83-100 15-29-43-62-81-100 17-33-50-67-83-100
4 6
Scroll
POE
0/100 0/100
1 1
PLATE PLATE
35 38
4 4
4.4 5.6
8 10
880 880
153000 190000
14.4 18.0
13.0 16.2
0 or 120 Pa (**)
2850 3559
2887 3599
0 0
0 0
Please consult factory
97 98
65 66
4000 5000
2200 2200
2550 2550
34
2106 2406
2 2
67 + 52 67 + 67
6 6
0/100 0/100
1 1
PLATE PLATE
38 40
4 4
6.7 6.7
10 12
880 880
204000 227000
18.0 21.6
16.2 19.5
3814 3932
3854 3975
0 0
0 0
98 99
66 67
6000 6000
2200 2200
2550 2550
