To access the CALIBRATION MENU simultaneously press
Ensure that the enter key is unlocked - section 3.4.1
Reference can additionally be made to the menu guide - section 4.2.
2.2

PROGRAMMING

See section 4.4.1
See section 4.4.2
See section 4.4.3
See section 4.4.4
See section 4.4.5
See section 4.4.6
See section 4.4.7
See section 4.4.8
See section 4.4.9
Measurement or Simulation (optional)
The actions which are highlighted in grey
measurement.
8045
QUICKSTART
Choose the
desired language
Select the desired
units
Calculate the
K Factor
Select current
output range
Select the pulse
output parameters
Configure relays
1 & 2 (if available)
Choose the
desired filter
Reset the totalizer
Selection of the
AC Frequency
5
ENTER
Ex. Select the units l/s with 1 decimal
point and select m 3 for the totalizer
display.
Ex. 4 mA = 0 l/s and
and 20 mA = 10 l/s.
Ex. 1 pulse corresponds to 100 l.
2 types of filter available each with 10
levels of damping.
To avoid resetting of the totalizer, set the
internal switch 2 into the locked position
(see § 3.4.1).
To cancel any noise generated
by the main AC frequency.
See the next page.
must be fully completed for accurate
for 5 seconds.
