3.5

CONNECTION EXAMPLES

CONTINUOUS PNEUMATIC FLOW CONTROL
REL 1
PLC
Jumper
Connection between the 8045 flow
transmitter 18-36VDC and the 1067
positioner mounted on a diaphragm
valve 2031.
(*) If direct earthing is impossible, connect a
100 nF / 50 V-condensator between the
negative terminal and the earth.
INSTALLATION
300 mA
1 2 3 4 5 6
+ -
P+ P-
24 V=
(*)
+ - + - + -
1 2 3 4 5 6
R1
7 8 9 10
4-20 mA
-
+ 24 V
PE
24 VDC
POSITIONER 1067
16
Connection between the 8045 flow
transmitter 18-36VDC and the
8630 Top Control mounted on a
diaphragm valve 2031.
(*) If direct earthing is impossible, connect a
100 nF / 50 V-condensator between the
negative terminal and the earth.
(*)
4-20 mA
REL 1
I/O4 I/O3 I/O2 I/O1 GND2 I2 U1 I1
GND1
0-10 V
4-20 mA
0/4-20 mA
24 V=
1 2 3 4 5 6
+ -
P+ P-
PLC
8045
