6.7 SPARE PARTS LIST
Position Designation
1 PC cover with lid, window and screws
2 PPA cover with lid, window and screws
3 PCB without relay
4 PCB with relays
1+3 PC cover with lid, screws, folio and PCB without relay
1+4 PC cover with lid, screws, folio and PCB with 2 relays
2+3 PPA cover with lid, screws, folio and PCB without relay
2+4 PPA cover with lid, screws, folio and PCB with 2 relays
5+13 PC housing for 2 cable glands + nut
PPA housing for 2 cable glands + nut
6+8+9+11 Set with 2 cable glands M20x1,5 + 2 neoprene flat seals
for cable gland or plug + 2 screw-plugs M20x1.5 +
2 multiway seals 2x6 mm
7+8+9 Set with 2 reductions M20x1,5 / NPT1/2'' + 2 neoprene flat
seals for cable gland or plug + 2 screw-plugs M20x1.5
10+11+14 Set with 1 cable gland obturator M20x1,5 + 1 multiway
seal 2x6 mm for cable gland or plug + 1 black EPDM gasket
for the sensor + 1 mounting instruction sheet
12 Ring
13 PC nut for PC housing
PPA nut for PPA housing
14 Set with 1 green FKM gasket + 1 black EPDM gasket
15 PVDF sensor, short, for DN15 up to 100 (1/2" - 4")
Stainless steel sensor, short, for DN15 up to 100 (1/2" - 4")
16 PVDF sensor, long, for DN >100 (> 4")
Stainless steel sensor, long, for DN >100 (> 4")
Instruction manual Fitting S020
Set incl. 8 "FLOW" folios without "relay" printing
Set incl. 8 "FLOW" folios with "relay" printing
8045
ANNEX
41
Order code
553189
553190
553173
553174
426530
426531
449757
449758
425526
449754
449755
551782
551775
619205
619204
440229
552111
444780
449759
444781
449760
429633
553191
553192
