Attached B

Technical specs:

Main structure
Metallic structure
Special metallic structure
Plastic and rubber spare parts
Upholstery
Paintings
Further information are available on the web site www.pilatech.com
Dimensions and maximum load:
Length
Width
Height
Weight
Max weight
capacity
Rev 2_1 2015
Solid beech wood.
The beech is one of the most resistant Italian noble wood. It is grown in
intensive cultivation and its use in our industry does not pauperise Italian
natural resources.
Other woods are available on demand.
The main metallic structure is made in stailess steel. It is later satin-finished
to improve aesthetics and to look more shining.
It is not subject to processes that may weaken its structure.
Welding procedures are carried out according to the TIGG method, an
advanced technology that guarantees high mechanical resistance standard.
Pins, joints, wheels, accessories and other components have been
developed and created to guarantee the highest mechanical resistance to
different stresses.
All these components are produced with certified materials that do not
contain toxic, allergenic or irritating substances.
Polilatex, our padding material, is the most innovative synthetic
polyurethane. It is hypoallergenic, transpiring, undeformable and eco-
friendly.
Being the results of long researches, its environmentally friendly water-
based and CFC-free composition enables air circulation, an optimum
humidity and temperature level and a good ergonomic support.
Both synthetic leather and upholstery have been chosen and created to be
highly comfortable during the exercises.
They are produced according to industry standards and are highly resistant
and durable.
Upholstery is available in different colors.
Like all other Pilatech tools, painting is carried out with water-based products,
according to the highest quality standard: fast colors, are pleasant to the
touch and last long.
Tests were carried out to check resistance to wear and to gurantee an
optimal anti-scratch level.
cm 237
cm 66,2
cm 37
Kg 76
Kg 120
Scheda Prodotto Pilatech Reformer CS2 - Manuale di montaggio e manutenzione
Projected by Ufficio Tecnico Pilatech
via F. Turati, 28/A
22060 CABIATE (CO) - Italy
Tel: +39 031 766599 – Fax +39 031 768691
email: info@pilatech.com
Assistance Pilatech Srl
via F. Turati, 28/A
22060 CABIATE (CO) - Italy
Tel: +39 031 766599 – Fax +39 031 768691
email: info@pilatech.com
pag 30 di 44
