Kärcher HKF 200 Originalbetriebsanleitung Seite 24

G
F
A Hanging bow (order no. 4.034-126)
B Standard length 800 mm, special edi-
tion 300-1500 mm
C Prescribed rotation direction
D Flange diameter 250 mm
E Hole circle diameter 225 mm
F Zone 0/20, category 1
G Zone 1, category 2 or 3
24
English
Measuring sheet HKF 200 E / HKF 200 C
I
250
H
H Pressure connection M22x1.5
I Hole layout of the mounting flange
J Cable input round cable (min. diameter
10 mm - 4x 1,5 mm
30
J
E
D
C
)
2
A
X
XX
X Minimum insertion diameter
180 mm
XX Rotation diameter 200 mm
