Kärcher HKF 200 Originalbetriebsanleitung Seite 30

A Support unit (support unit with seat con-
tact button = option)
B Grid
C Option
D Filter monitoring
E Wire split filter
F Exhaust air
G Clear flushing liquid supply, by custom-
er
H Suction filter, swivellable
I Sieve
J Compact circuit basin
Length x width x height = 2700 mm x
1500 mm x 650 mm
K Compressed air 0.4-0.7 MPa -300 l/min
L Compressed air filter
M Maintenance unit
Cleaning liquids
solvents
Danger
– The explosion protection must be taken
into consideration when operating with
solvents as well as in EX zones!
– Maximum pressure with solvent opera-
tion: 5 MPa
– Maximum flow volume with solvent op-
eration: 50 l/min
Warning
When operating with solvents, the sealing
materials are less resistent, therefore they
must be flushed immediately after use! En-
quire with Kärcher!
1 Hydrocarbons
Example: Petroleum
2 Aromates (solvents)
Example: Benzene, toluene
30
English
Installation example HKF 200 PU
3 Ketones
Example: MEK (Methyle Ethyle Ke-
tones), Acetone
4 Ester
Example: Butylacetate, Methylacetate
5 Glycoles
Example: Butyl glycole
6 Mixed solvents
Example: Butyl acetate 85, Isobutyl ac-
etate 85 (85 = 85% Butyl acetate + 15%
n-Butanol)
7 Regenerates, distillates from different
solvents, which have already been used
for cleaning purposes or similar applica-
tions.
Brines
1 Water with alkaline cleaning agents
(max. 0-2%)
Example: Kärcher cleaning agents
RM31
2 Caustic soda max. 10%, without hy-
pochlorite particles
3 Potassium hydroxide max. 10%, without
hypochlorite particles
Acids
Warning
– The material will be worn off faster when
using hydrochloric or sulfuric acids;
therefore it must be rinsed/neutralised
immediately!
– Contaminated acids will decrease the
resilience!
– Enquire with Kärcher if needed!
1 Water with acid cleaning agents (max.
0-1%)
Example: Kärcher cleaning agents
RM25
2 Acids (max. temperature +20 °C)
Nitric acid max. 10%.
Acetic acid max. 10%.
Formic acid max. 10%.
Phosphoric acid max. 10%.
Citric acid max. 10%.
Sulfuric acid max. 0.5%.
Hydrochloric acid max. 0.5%.
Water
1 Water
2 Fully desalted water
Other cleaning liquids
If other cleaning liquids are used, their resil-
ience must be checked by means of the
materials list! These cleaning liquids can
only be used after being released by Kärch-
er!
