h) Set transmission command

The transmission command determines how the receiver responds to a switching signal.
There are various possible responses (see table below).
Required
2-digit number
11
12
13
14
21
22
23
24
31
32
33
34
41
42
43
44
2
1
or
2
1
hold down for 5 seconds
Status LED D1 flashes
1 2
Enter transmission command
Status LED D1 goes out
54
Transmission command
on (last level of brightness)
off
on (brightness 12.5 %)
on (brightness 25.0%)
on (brightness 37.5%)
on (brightness 50.0%)
on (brightness 62.5%)
on (brightness 75.0%)
on (brightness 87.5%)
on (brightness 100%)
off for on-time
on (last level of brightness) for on-time, then off
on (brightness 100 %) for on-time, then off
on (last level of brightness) for on-time, then back to previous level
of brightness (not every receiver supports this command)
on (brightness 100 %) for on-time, then back to previous level
of brightness (not every receiver supports this command)
on (last level of brightness)
Channel 1
4
3
Channel 2
4
3
3 4
• To set channel 1, hold down button 1 for 5
seconds, until status LED D1 flashes.
Use button 3 for channel 2.
• Then enter the transmission command
according to the table above (34 for factory
settings).
• When the new settings are entered, status
LED D1 goes out.
