Parameterbeschreibungen
6-29 Klemme 54 Funktion
Option: Funktion:
Wählen Sie aus, ob Klemme 54 für Strom- oder
Spannungseingang verwendet wird.
[0] Strom
[1] Spannung
*
6-90 Terminal 42 Mode
Option: Funktion:
Konfigurieren Sie Klemme 42 für die
Funktion als Analog- oder Digitalausgang.
Wenn Digitalausgang eingestellt ist, gibt
Klemme 42 0 mA als AUS oder 20 mA als
EIN ein. Sie müssen den externen
Widerstand (≥1 kΩ) zwischen den Klemmen
42 und 55 anschließen.
[0] 0-20 mA
*
[1] 4-20 mA
[2] Digital-
ausgang
6-91 Terminal 42 Analog Output
Option:
[0] No operation
*
[100] Output frequency
[101] Reference
[102] Process Feedback
[103] Motor Current
[104] Torque rel to limit
[105] Torq relate to rated
[106] Power
[107] Speed
[111] Speed Feedback
[113] Ext. Closed Loop 1
[139] Bus Control
[143] Ext. CL 1
[254] DC Link Voltage
6-92 Terminal 42 Digital Output
Option:
[0] No operation
*
[1] Control Ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Stand-by / no warning
[5] Running
[6] Running / no warning
[7] Run in range/no warn
[8] Run on ref/no warn
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
MG07C303
Programmierhandbuch
Funktion:
Funktion:
Danfoss A/S © 07/2016 Alle Rechte vorbehalten.
6-92 Terminal 42 Digital Output
Option:
[14] Above current, high
[15] Out of frequency range
[16] Below frequency, low
[17] Above frequency, high
[18] Out of feedb. range
[19] Below feedback, low
[20] Above feedback, high
[21] Thermal warning
[22] Ready, no thermal
warning
[23] Remote,ready,no TW
[24] Ready, no over-/ under
voltage
[25] Reverse
[26] Bus OK
[27] Torque limit & stop
[28] Brake, no brake warning
[29] Brake ready, no fault
[30] Brake fault (IGBT)
[31] Relay 123
[32] Mech brake ctrl
[36] Control word bit 11
[37] Control word bit 12
[40] Out of ref range
[41] Below reference, low
[42] Above ref, high
[45] Bus ctrl.
[46] Bus control, timeout: On
[47] Bus control, timeout: Off
[56] Heat sink cleaning
warning, high
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[70] Logic rule 0
[71] Logic rule 1
[72] Logic rule 2
[73] Logic rule 3
[74] Logic rule 4
[75] Logic rule 5
[80] SL digital output A
[81] SL digital output B
[82] SL digital output C
[83] SL digital output D
[160] No alarm
[161] Running reverse
[165] Local ref active
[166] Remote ref active
[167] Start command activ
Funktion:
