Safety Precautions - Rotex RRHQ006ADV3 Installationsanleitung

RRHQ006ADV3 RRHQ006ADV38
RRHQ007ADV3 RRHQ007ADV38
RRHQ008ADV3 RRHQ008ADV38
C
ONTENTS

Safety precautions............................................................................. 1

Model ................................................................................................ 2
Accessories....................................................................................... 2
Installation guidelines........................................................................ 2
Precautions for selecting the location ........................................................ 2
Selecting a location in cold climates .......................................................... 2
Refrigerant piping specifications................................................................ 3
Installing near a wall or obstacle................................................................ 3
Outdoor unit installation drawing ............................................................... 3
Installation procedure........................................................................ 4
Mounting the outdoor unit .......................................................................... 4
Drain work.................................................................................................. 4
Flaring the pipe end ................................................................................... 4
Connecting the refrigerant piping to the outdoor unit ................................ 4
Refrigerant piping work.............................................................................. 5
Purging air and checking gas leakage....................................................... 5
Charging refrigerant................................................................................... 6
Wiring ........................................................................................................ 6
Test run and final check .................................................................... 8
Trial operation and testing.......................................................................... 8
Items to check............................................................................................ 8
Pump down operation ....................................................................... 8
Pump down procedure............................................................................... 8
Forced cooling operation ........................................................................... 8
Disposal requirements ...................................................................... 8
READ THESE INSTRUCTIONS CAREFULLY BEFORE
INSTALLATION. KEEP THIS MANUAL IN A HANDY
PLACE FOR FUTURE REFERENCE.
IMPROPER INSTALLATION
EQUIPMENT OR ACCESSORIES COULD RESULT IN
ELECTRIC SHOCK, SHORT-CIRCUIT, LEAKS, FIRE OR
OTHER DAMAGE TO THE EQUIPMENT. BE SURE ONLY
TO USE ACCESSORIES MADE BY ROTEX WHICH ARE
SPECIFICALLY DESIGNED FOR USE WITH THE
EQUIPMENT AND HAVE THEM INSTALLED BY A
PROFESSIONAL.
IF UNSURE OF INSTALLATION PROCEDURES OR USE,
ALWAYS CONTACT YOUR ROTEX DEALER FOR
ADVICE AND INFORMATION.
S
AFETY PRECAUTIONS
This manual classifies the precautions into WARNING and
CAUTION. Be sure to follow all the precautions below: they are
all important for ensuring safety.
Failure to follow any of WARNING is likely to result in such
grave consequences as death or serious injury.
Failure to follow any of CAUTION may in some cases result
in grave consequences.
The following safety symbols are used throughout this manual.
Be sure to observe this instruction.
Be sure to establish an earth connection.
Never attempt.
Installation manual
1
Outdoor unit for air to water heat pump
Page
OR ATTACHMENT OF
After completing installation, test the unit to check for installation
errors. Give the user adequate instructions concerning the use
and cleaning of the unit as included in the operation manual of
the indoor unit.
Warnings
Installation should be left to the dealer or another professional.
Improper installation may cause water leakage, electrical shock,
or fire.
Install the outdoor unit according to the instructions given in this
manual.
Incomplete installation may cause water leakage, electrical
shock, or fire.
Be sure to use the supplied or specified installation parts.
Use of other parts may cause the unit to vibrate loose, and may
cause water leakage, electrical shock, or fire.
Install the outdoor unit on a solid base that can support the
weight of the unit.
An inadequate base or incomplete installation may cause injury
in the event the unit falls off the base.
Electrical work must be carried out in accordance with the
installation manual and the national electrical wiring rules or
code of practice.
Insufficient capacity or incomplete electrical work may cause
electrical shock or fire.
Be sure to use a dedicated power circuit. Never use a power
circuit shared by another appliance.
For wiring, use a cable long enough to cover the entire distance
with no connection. Do not use an extension cord. Do not put
other loads on the power supply, use a dedicated power circuit.
Failure to do so may cause abnormal heat, electric shock, or fire.
Use the specified types of wires for electrical connections
between the indoor and outdoor unit.
Firmly clamp the interconnecting wires so that their terminals
receive no external stress. Incomplete connections or clamping
may cause terminal overheating or fire.
After connecting the interconnecting and supply wiring, be sure
to shape the cables so that they do not put undue force on the
electrical covers or panels.
Install covers over the wires. Incomplete cover installation may
cause terminal overheating, electrical shock, or fire.
If any refrigerant has leaked out during the installation
work, ventilate the room.
The refrigerant produces a toxic gas if exposed to
flames.
After all installation is complete, check to make sure
that no refrigerant is leaking.
The refrigerant produces a toxic gas if exposed to
flames.
When installing or relocating the system, be sure to keep the
refrigerant circuit free from substances other than the specified
refrigerant (R410A), such as air.
Any presence of air or other foreign substance in the refrigerant
circuit causes an abnormal pressure rise or rupture, resulting in
injury.
During pump down operation, stop the compressor before
removing the refrigerant piping.
If the compressor is still running and the stop valve is open
during pump-down, air will be sucked in when the refrigerant
piping is removed, causing abnormal pressure in the freezer
cycle which will lead to breakage and even to injury.
Installation manual
RRHQ006~008ADV3(8)
Outdoor unit for air to water heat pump
4PW52843-1
