TMT162
®
Available in ReadWin 2000, HART
Commuwin II with Matrix address
Cold junction Selection of the internal (Pt100) or an external comparison
measurement point.
Input:
• internal
• external
Function is only active on selection of a thermocouple (TC) in the device function
SENSOR TYPE (V3H0).
External Input of the external comparison point measurement value.
temperature Input: -40.0 to 185.0 °F / -40.00 to 85.00 °C (°C, F, K)
32 °F (0 °C)
Function is only active when "external" has been selected in the device function
COLD JUNCTION (V3H2).
2-wire Input of cable resistance compensation on a 2-wire RTD connection.
Input: 0.00 to 30.00 Ω
compensation
Function is only active when a 2-wire connection has been selected in the device
function SENSOR CONNECTION (V3H1).
Offset Input of the zero point correction (offset).
Input: -18.00 to 18.00 °F (-10.00 to 10.00 °C)
32.0 °F (0.00 °C)
Measurement Display of measurement unit.
unit Sensor 1 unit = PV unit
Serial no. Input of the serial number of the sensor connected to this sensor input.
sensor
®
Available in ReadWin 2000, HART
Commuwin II with Matrix address
Sensor type See Function group SENSOR 1
Sensor 1 has priority, sensor 2 setup is matched to the setup of sensor 1.
Example: Sensor 1 is set up for a 4-wire connection, sensor 2 is set up for a 3-wire
connection; there is an automatic change of sensor 2 to a type K thermocouple.
Sensor See Function group SENSOR 1
connection
Cold junction See Function group SENSOR 1
External See Function group SENSOR 1
temperature
2-wire See Function group SENSOR 1
compensation
Offset See Function group SENSOR 1
Measurement See Function group SENSOR 1
unit
Serial no. See Function group SENSOR 1
sensor
Endress+Hauser
Function group SENSOR 1
®
handheld module DXR275/375 (Symbol
Function group SENSOR 2 (only on a device with 2 sensor inputs)
®
handheld module DXR275/375 (Symbol
7
®
), ReadWin 2000
+
+
+
+
+
+
7
®
), ReadWin 2000
+
+
+
+
+
+
+
+
Commissioning
7
/FieldCare CW II-
Matrix
+ V3H2
+ V3H3
+ V3H4
+ V3H5
+ V3H6
+ V3H7
7
/FieldCare CW II-
Matrix
+ V4H0
+ V4H1
+ V4H2
+ V4H3
+ V4H4
+ V4H5
+ V4H6
+ V4H7
