5.3.1 HART Communicator DXR275/375
®
With the HART handheld module, all device functions are selected by means of various
menu levels with the aid of the function matrix (see Fig. 10). All the device functions are
explained in chapter 6.4.1 "Description of Device Functions".
Procedure:
1. Switch on the handheld module:
– Measuring device not yet connected. The HART
appears for every HART
Information on off-line configuration can be found in the Operating Instructions of the
"Communicator DXR275/375" handheld module.
– Measuring device is already connected. The 1st menu level of the device function matrix
appears directly (see Fig. 9). All the functions accessible under HART
arranged in this matrix.
2. Select the function group (e.g. Sensor 1) and then the desired function, e.g. "Sensor type 1".
3. Enter type or change the setting. Then confirm with the function key F4 "Enter".
4. "SEND" appears via the function key "F2". Pressing the F2 key transfers all the values entered
with the handheld module to the device measuring system.
5. With the "F3" function key HOME, you return to the 1st menu level.
®
• With the HART
disabled. However, you can enable the HART
SECURITY LOCKING function. The enable status is retained even after a power failure.
Delete the release (or unlock) code 261 to lock the HART
• Detailed information can be found in the HART
module transport pouch.
Fig. 9: Configuration at the handheld module, using 'Sensor input' as an example
®
programming, i.e. irrespective of the measuring device type.
handheld module, all parameters can be read and programming is
®
main menu appears. This menu level
®
are systematically
®
function matrix by entering 261 in the
®
function matrix again.
®
instruction manual in the handheld
