Motors of the 400 V class

Part Number M
max
A1.SM.000-6400 1.7
A2.SM.000-6400 2.5
A3.SM.000-6400 3.2
A4.SM.000-6400 5
B1.SM.000-4400 3.1
B1.SM.000-6400 3.1
B2.SM.000-4400 7.2
B2.SM.000-6400 7.2
B3.SM.000-4400 11
B3.SM.000-6400 11
C1.SM.000-3400 4.3
C1.SM.000-4400 4.3
C1.SM.000-6400 4.3
C2.SM.000-3400 12.2
C2.SM.000-4400 12.2
C2.SM.000-6400 12.2
C3.SM.000-3400 20.3
C3.SM.000-4400 20.3
C3.SM.000-6400 20.3
C4.SM.000-3400 27
C4.SM.000-4400 27
C4.SM.000-6400 27
D1.SM.000-3400 18.9
D1.SM.000-4400 18.9
D1.SM.000-6400 18.9
D2.SM.000-3400 31.5
D2.SM.000-4400 31.5
ⓐ
ⓑ
ⓐ: Short-time duty
ⓑ: Continuous operation
M M n n
d0 N N Mmax
[Nm] [Nm] [rpm]
0.34 0.32 6000 7550
0.5 0.48 6000 6900
0.65 0.6 6000 6600
1 0.8 6000 6000
0.65 0.6 4000 2800
0.65 0.5 6000 5200
1.5 1.3 4000 1850
1.5 1 6000 4800
2.3 2 4000 3100
2.3 1.5 6000 4500
0.95 0.8 3000 1500
0.95 0.75 4000 2850
0.95 0.7 6000 4750
2.7 2.4 3000 2500
2.7 2.2 4000 4000
2.7 2 6000 6150
4.5 3.9 3000 2650
4.5 3.5 4000 3850
4.5 2.8 6000 5450
6 5 3000 2750
6 4.5 4000 3950
6 3 6000 6300
4.2 3.7 3000 2500
4.2 3.5 4000 3850
4.2 3 6000 5600
7 6.1 3000 2650
7 5.8 4000 3650
n Part Number
0
11950 D2.SM.000-6400
10050 D3.SM.000-3400
9350 D3.SM.000-4400
8250 D3.SM.000-6400
6850 D4.SM.000-3400
10250 D4.SM.000-4400
5750 E1.SM.000-2400
8800 E1.SM.000-3400
5450 E1.SM.000-4400
7850 E2.SM.000-2400
4950 E2.SM.000-3400
6550 E2.SM.000-4400
9800 E3.SM.000-2400
4150 E3.SM.000-3400
5550 E3.SM.000-4400
8350 E4.SM.000-2400
3950 E4.SM.000-3400
5100 F1.SM.000-1400
7600 F1.SM.000-2400
4100 F1.SM.000-3400
5350 F1.SM.000-4400
7750 F2.SM.000-1400
3950 F2.SM.000-2400
5300 F2.SM.000-3400
7950 F3.SM.000-1400
3900 F3.SM.000-2400
5200 F3.SM.000-3400
Technical Data
M M M n
max d0 N
[Nm] [Nm]
31.5 7 3.8 6000
45 10 8.4 3000
45 10 7.6 4000
45 10 5 6000
54 12 9.9 3000
54 12 8.6 4000
42 8.5 7 2000
42 8.5 6.5 3000
42 8.5 5.2 4000
70 14 12.2 2000
70 14 11 3000
70 14 7.6 4000
85 19 16.5 2000
85 19 14.6 3000
85 19 8.7 4000
121 27 21.4 2000
121 27 15.5 3000
88 25 22.5 1500
88 25 21.5 2000
88 25 20 3000
88 25 16 4000
175 50 42 1500
175 50 38 2000
175 50 31 3000
245 70 61 1500
245 70 52 2000
245 70 33 3000
n n
N Mmax 0
[rpm]
6550 8050
2850 3850
3900 5250
5900 7350
3000 3800
4150 5200
1550 2300
2350 3500
3550 4600
1550 2250
2500 3400
3600 4500
1800 2300
2750 3550
3850 4650
1700 2200
2650 3250
600 1700
1200 2300
1800 3550
2850 4650
950 1800
1300 2400
2300 3450
1200 1750
1700 2350
2900 3550
