Connection
4.
Connection
The connection must be carried out in such a way that a permanently safe, electrical connection is
maintained. Pay attention to a safe protective conductor connection. By turning the flange sockets
any outgoing cable direction can be adjusted (rotatable by 90° each).
In the case of improper execution of the work the type of protection IP65 is no longer warranted. If
connector systems are used, then the type of protection IP65 is only achieved with correctly wired
and firmly tightened mating connector.
4.1
Conductor cross-section
The recommended values for the dimensioning of the conductor cross-sections are given in the table. They are
specified in DIN VDE 0113 (EN 60 204) „Electrical equipment of industrial machines" for the current carrying capa-
city of PVC-insulated cables with copper conductor routed in cable ducts. The maximum permissible surrounding
temperature is +40°C.
Conductor size [mm²]
4.2
Power unit
Power unit connection
•
Angle socket
•
rotatable
•
8-pole
•
Plug
View of the connector pins at
the motor
Terminal assignment
Motor cable for
ready-made, shielded, trai-
ling capable
GB - 20
1.5
2.5
4
1
U
2
PE
3
W
4
V
A
Brake + (option)
B
Brake - (option)
C
Temperature detector +
GB
Temperature detector -
x - cross-section [mm²]
0 = 1.5 mm²; 1 = 2.5 mm²
perm. maximum current (actual value) [A]
Ax...Dx.SM.5
3
D
C
2
4
B
A
1
Ax...Dx.SM.5
00S4x19-yyyy
yyyy - line length [m]
13.5
18.3
24
Ex.SM.5
-
V
W
2
U
U
V
V
W
W
PE
+
Brake + (option)
-
Brake - (option)
1
Temperature detector +
2
Temperature detector -
Ex.SM.5
00S4x19-yyyy
x - cross-section [mm²]
2 = 4 mm²
+
U
1
