1.3

Transport and packaging

The packaging and transport technologies are dependent on the shipping conditions. The following types of pa-
ckaging are provided:
• Folding boxes
• Covered and steel-strapped flat pallets (transport by truck)
• Special pallets
• Special packaging in wooden cases
The motors should always be shipped so that no damage can occur in transit.
Caution during
transport
After final tests all motors leave the factory in perfect condition. Make a visual check for any external damage
immediately upon their arrival on site. If any damage caused in transit is found, make a notice of claim in the pre-
sence of the forwarder. In addition, report the damage to the manufacturer at the latest within one week. Do not
put these motors into operation.
1.4

Storage

If the motors are not installed immediately after their arrival, they should be properly stored. Store the motors only
in closed, dry, dust-free, well-ventilated and vibration-free rooms. Damp rooms are unsuitable for storage ! Do not
remove the anti-corrosive coat from the shaft ends, flange surfaces etc. Check it at certain intervals depending on
the ambient conditions and touch up, if required
Take care that no vibrations occur in storage to prevent the anti-friction from being damaged. It is advisable to turn
the rotor several times at certain intervals to prevent corrosion of the bearings.
After a longer storage (> 3 months) operate the motor at slow speed (< 100 min
lubrication can spread evenly in the bearings.
1.5

Standards, codes and regulations

Servo motors are designed in accordance with IEC recommendations and the applicable VDE and DIN standards
(see table opposite). The motors are manufactured in accordance with the international quality standards ISO
9001.
Title
Rotating electrical machines; rating and performance DIN VDE 0530 Part 1
Terminal markings and direction of rotation
Classification of types of construction and mounting
arrangements
Methods of cooling
Classification of degree of protection by enclosures
Mechanical vibration of certain machines - Measure-
ment, evaluation and limits of vibration severity
Noise limits
Avoid any impacts, sharp sudden movements and strong vibrations during trans-
port. Operate the crane only at creeping speed to lift or place down the motors.
This prevents damage to the bearings or the machine.
DIN/VDE
DIN VDE 0530 Part 8
DIN VDE 0530 Part 7
DIN VDE 0530 Part 6
DIN VDE 0530 Part 5
DIN VDE 0530 Part 14
DIN VDE 0530 Part 9
General
) in both directions, so that the
-1
EN IEC
EN 60 034-1 IEC 600 34-1
EN 60 034-8 IEC 600 34-8
EN 60 034-7 IEC 600 34-7
EN 60 034-6 IEC 600 34-6
EN 60 034-5 IEC 600 34-5
EN 60 034-14 IEC 600 34-14
EN 60 034-9 IEC 600 34-9
further on next side
