FIRE
EXTINGUISHING
EQUIPMENT
When choosing the most suitable fire extin-
guisher consult the following table:
Dry
combus-
tibles
Water YES
Foam YES
Dry
YES*
chemical
CO YES*
2
YES* Use only if more appropriate
extinguishers are not on hand or when the
fire is small.
28
Inflam- Electrical
mable fires
liquids
NO NO
YES NO
YES YES
YES YES
CAUTION
The indications given in this table are of
a general nature and should be used as a
general guide. All the applications of each
type of extinguisher must be obtained from
the relevant manufacturer.
COMPRESSED AIR
SYSTEM DIAGRAM
1 Pressure regulator
2 Valve 5/3
3 Cylinder
Operator's manual HELPER 4FD
