• Injuries due to defective saw band. Check the integ-
rity of the saw band regularly.
• Danger of injury for fingers and hands when chang-
ing the saw band. Wear suitable work gloves.
• Danger of injury when the machine is switched on
from the running saw band.
• Hazard due to electrical power, with the use of im-
proper electrical connection cables.
• Danger to health from running saw band due to long
hair and loose clothing. Wear personal protective
equipment such as a hair net and close-fitting work
clothing.
• The rollers can continue to rotate if a drive belt or a
saw blade breaks. Always wait for the machine to
come to a complete stop before opening the sepa-
rating guards.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the "General
safety instructions" and the "Proper use" are ob-
served along with the whole of the operating in-
structions.
6. Technical data
Max. admission width
Max. admission height
Table size
Cutting speed
Saw band length
Height up to tabletop
Height up to tabletop with ma-
chine stand
Overall height without machine
stand
Overall height with machine
stand
Overall width
Total depth
Pivot range of the table
Weight (230-240V)
Weight (400V)
Extraction connection
38 | GB
Max. installation altitude
(above sea level)
Drive
Engine
Nominal consumption P1 (kW)
Power output P2 (kW)
Drive
Engine
Nominal consumption P1 (kW)
Power output P2 (kW)
*Operating mode S1 (continuous operation)
The machine can be operated continuously with the
specified power.
* Operating mode S6 40%:
Continuous duty with intermittent loading (operating
time 10 min.)
306 millimeters
205 millimeters
In order avoid impermissible overheating of the motor,
400 x 548 mm
the motor should be driven for only 40% of the operat-
ing time with the stipulated nominal power and must
370 – 750 m/min
then continue to run with no load for the remaining 60%
2360 millimeters
of the operating time.
490 millimeters
Subject to technical changes!
1025 millimeters
The workpiece must have a minimum height of 3 mm
and a minimum width of 10 mm.
1125 millimeters
Noise data
1655 millimeters
Measurement per ISO 19085-16:2021, Annex F, using:
ISO 3744:2010 for the noise power: ISO 3746:2010 with
900 millimeters
accuracy class 3 for the emission sound pressure: ISO
540 millimeters
11202:2010 with accuracy class 3.
Operating conditions during the measurements: ISO
-11° – +45°
19085-16:2021, F.5.
Approx.
78.4/84.4kg
If the specified emission values are to be checked, the
Approx.
measurements must be carried out using the same
74.5/80.5kg
procedure and under the same operating and installa-
Ø 100 mm
tion conditions as those specified.
www.scheppach.com
1000 m
AC
230-240 V ~ 50 Hz
0.8kW (S1)
1.1 kW (S6 40%)
0.56kW (S1)
0.74 kW (S6 40%)
3-phase 400 V
3-phase ~ 50 Hz
0.7kW (S1)
1.1 kW (S6 40%)
0.48kW (S1)
0.77 kW (S6 40%)
