Setting the wel- Requirement:
ding parameters -
-
1
2
3
The value and the icon of the welding parameter are displayed in white. The wel-
ding parameter has been set.
Saving an Easy-
The 4 EasyJob buttons can be assigned with EasyJobs, which can be retrieved at
Job the touch of a button.
NOTE!
The EasyJobs are stored under job numbers 1 – 4 and can also be retrieved on
the welding machine via Job Mode.
▶
1
After 3 seconds, a symbolized button with a green frame and the Save symbol is
shown on the display. The most recently used settings have been saved and are
now activated.
Retrieving an Ea-
1
syJob
40
The value of the welding parameter is displayed in gray.
The welding parameter icon is displayed in white between 2 blue lines.
Turn the left-hand dial and select the desired welding parameter.
Press the left-hand dial.
The value of the welding parameter is displayed in white and can now be
changed.
Turn the right-hand dial and adjust the value of the correction parameter.
Storing an EasyJob overwrites a job stored under the same job number.
Press and hold one of the 4 EasyJob buttons for 3 seconds.
To retrieve a saved EasyJob, press and hold the corresponding EasyJob but-
ton briefly (< 3 seconds).
