Status indicators

Status indicators
28
Status indicator
The color and animation of the status indicator show the current function
and/or which mode is currently running.
Right-hand dial with rotary/push button function
For selecting and setting parameters in the right-hand display section.
Central display section
Welding-relevant data are displayed in the central display section. These
differ depending on the welding process selected.
For details see Icons in the central display section
Right-hand display section
The right-hand display section shows parameters and functions that are
set using the right-hand dial. The parameters displayed vary according to
the set welding process.
EasyJob buttons
For saving, selecting, and deleting EasyJobs.
Status bar 1
Contains information about:
- The currently selected welding process
-
The currently selected operating mode
- The active process function
For details see Icons in status bar 1
Status bar 2
Contains information about the logged-in user, the welding data, and the
single-phase power supply.
For details see Icons in status bar 2
Color
Green
Blue animated
Red
Orange
White
Yellow animated
Mint animated
Green animated
on page 29.
on page 29.
on page 30.
Meaning
Device is ready for welding
Welding is active
Error
Warning
Notification
Gas test is active
Wire threading is active
Device starting up or restarting
