Icons In Status Bar - Fronius Rc Panel Smart/Tmc Bedienungsanleitung

Icon
Icon
Icons in status Status bar 2
bar 2
Icon
-
1)
30
Currently set operating mode
Special 4-step mode (S4-step)
Spot welding (Spot)
Active process functions
Welding characteristic property
SynchroPulse (SynchroPulse)
Stitch welding
Tacking (TAC) during TIG welding
Remote control active
The icon lights up green when a remote control with va-
riable resistance control is connected. The settings on
the remote control take precedence over those on the
welding machine.
Explanation
The remote control is locked. The operating elements
cannot be used to change any parameters.
Current welding data (welding current [A], wire speed
[m/min], welding voltage [V])
Different values are displayed depending on the work
step:
-
-
-
Single-phase power supply
lights up green during single-phase operation
Foot-operated remote control
lights up gray during TIG welding when a foot-operated
remote control is connected
Available only for Fortis /XT devices.
When setting the set value
The actual value during welding
The mean value after welding (Mean)
1)
