8 SPECIFICATIONS
8.1 Base Unit Specifications
Expected Service Life .................................................................................................................. 7 Years
Measurement Range ............................................................................................................... ..0-100%
Resolution ........................................................................................................................................ 0.1%
Accuracy and Linearity ........................................1% of full scale at constant temperature, R.H. and
Total Accuracy ........................................... ±3% actual oxygen level over full operating temp range
Response Time ........................................... 90% of final value in approximately 15 seconds at 23°C
Warm-up Time ............................................................................................................... None required
Operating Temperature ................................................................................ 15°C - 40°C (59°F - 104°F)
Storage Temperature ..................................................................................... -15°C - 50°C (5°F - 122°F)
Atmospheric Pressure ............................................................................................... .. 800-1013 mBars
Humidity ......................................................................................................0-95% (non-condensing)
Power Requirements............................................................... 2, AA Alkaline batteries (2 x 1.5 Volts)
Battery Life ............................................................. approximately 5000 hours with continuous use
Low Battery Indication............................................................................. "BAT" icon displayed on LCD
Sensor Type ......................................................................... Maxtec Max-250 series galvanic fuel cell
Expected Sensor Life ........................................................... > 1,500,000 O2 percent hours minimum
A Model dimensions................................... 3.0"(W) x 4.0"(H) x 1.5"(D) [76mm x 102mm x 38mm]
A Weight ........................................................................................................................... 0.4 lbs (170g)
AE Model Dimensions ............................... 3.0"(W) x 36.0"(H) x 1.5"(D) [76mm x 914mm x38mm]
AE Weight ........................................................................................................................ 0.6 lbs (285g)
Drift of Measurement ......... < +/-1% of full scale at constant temperature, pressure and humidity
Wattage Rating ........................................................................................ 3V
Storage temperature limits to operational use:
Cool-Down time ............................................................................................................ 5 Minutes
Warm-up time ........................................................................................................... 30 Minutes
8.2 Sensor Specifications
Type ......................................................................................................Galvanic fuel sensor (0-100%)
Life ........................................................................................................ 2-years in typical applications
INTERFERENT VOLUME % DRY
Nitrous Oxide 60% Balance O
Halothane 4%
Isoflurane 5%
Enflurane 5%
Sevoflurane 5%
Desflurane 15%
Helium 50% Balance O
9 MAXO2+ SPARE PARTS
AND ACCESSORIES
9.1 Included With Your Unit
PART NUMBER ITEM (EXPECTED SERVICE LIFE)
R217M40 User Guide & Operating Instructions (N/A)
RP76P06 Lanyard (Lifetime of MaxO2+)
R110P10-001 Flow Diverter (2 Years)
RP16P02 "T" Adapter (Single Use)
WWW.MAXTEC.COM • (800) 748-5355
pressure when calibrated at full scale
(2-year in typical medical applications)
Height includes length of external cable (retracted)
INTERFERENCE IN O2%
< 1.5%
2
< 1.5%
< 1.5%
< 1.5%
< 1.5%
< 1.5%
< 1.5%
2
A MODEL
X
X
X
X
R217P23 Dovetail Bracket (N/A)
R125P02-011 Max-250+ Oxygen Sensor (2 Years)
R125P03-002 Max-250E Oxygen Sensor (2 Years)
0.2mW
AE MODEL
X
X
X
X
9
x
x
x
