English
7.2 Deactivating the Bluetooth
Radio Interface
► If the battery has a Bluetooth
Press and hold the pushbutton until the
®
"BLUETOOTH " LED next to the
lights up blue six times.
®
The Bluetooth radio interface on the battery
is deactivated.
8 Assembling the Saw
8.1 Mounting and Removing the
Bar and Chain
8.1.1 Mounting the Guide Bar and Saw
Chain
The guide bar and saw chain combinations that
can be used with the chain sprocket are listed in
the specifications,
► switch off chain saw, engage chain brake and
remove battery
1
► Unscrew the nut (2).
► Remove the chain sprocket cover (1).
► Turn the tensioning screw (3) counterclock‐
wise until the tensioner slide (4) butts against
the left end of the housing.
42
®
®
radio interface:
symbol
22.1.
2
3
4
► Fit the saw chain in the guide bar groove so
that the arrows on the tie straps on the top of
the bar point in the direction of rotation.
5
8
6
7
► Fit the guide bar and chain on the saw and
check the following points:
– The drive links of the saw chain are seated
in teeth of the chain sprocket (5).
– The head of screw (6) is seated in the slot in
the guide bar (8).
– The peg of tensioner slide (4) engages the
hole (7) in guide bar (8).
The guide bar (8) may be fitted either way round.
The logo on the guide bar (8) may also be upside
down.
► Disengage the chain brake.
► Turn the tensioning screw (3) clockwise until
the saw chain fits snugly against the guide
bar. Make sure the drive links of the saw chain
engage the guide bar groove.
The guide bar (8) and saw chain are posi‐
tioned against the chainsaw.
► Fit the chain sprocket cover (1) so that it is
flush with the chainsaw.
► Fit and tighten down the nut (2).
8 Assembling the Saw
3
