19. Scroll to the #2 box for curve selection, and press the scroll wheel to select the Stunt #2 curve.
Set the Curve Values to:
1
2
0
25
20. Scroll to the H box for curve selection and press the scroll wheel to select the Hold curve.
Set the Curve Values to:
1
2
25
37
21. Scroll up to LIST, and press the scroll wheel to return to the Function List.
22. Scroll down to Mixing, and press the scroll wheel Select Mix 1. Select Normal.
Select the rst INH, and select the I Switch.
Select the second INH, and select A5.
Set the First Rate Value to: 0% the Second Rate Value to: -125%.
Set the Offset to 100. Set the Switch to the I button.
23. Scroll up to Back, and press the scroll wheel to return to the Function List.
24. Scroll down to Timer, and press the scroll wheel. Set to:
Mode: Count Down
Time: 5:00
Start: Throttle Out
Over: 25%
One Time: Inhibit
25. Scroll up to LIST, and press the scroll wheel to return to the Function List.
26. Scroll up to <Main Screen>, and press the scroll wheel.
See the Smart Throttle section for information on telemetry setup.
iX Series Transmitter Setup
1. Power ON your transmitter and begin once the Spektrtum AirWare app is open. Tap the orange pen icon in the
screen's upper left corner. The system asks for permission to Turn Off RF, select PROCEED.
2. Select the three dots in the upper right corner of the screen, select Add a New Model.
3. Select Model Option, choose DEFAULT, select Helicopter.
The system asks if you want to create a new heli model, select Create.
4. Select the last model on the list: Heli. Tap on Heli, and rename the model to a name of your choice.
5. Tap and hold the back arrow icon in the upper left corner of the screen to return to the main screen.
6. Tap on the Model Setup button.
7. Set Flight Mode Setup. Switch 1: Switch B. Hold Switch: Switch H.
Tap on the arrow in the upper left corner to return to the Model Setup menu.
8. Set Channel Assign. Set CH/Port 5 to Aux 5 for Output and Switch B for Input.
Tap on the arrow in the upper left corner to return to the Model Setup menu.
Tap on the arrow in the upper left corner to return to the main screen.
9. Tap on the Model Adjust button.
10. Tap on Dual Rates and Exponential. Tap on the pull down tab at Channel and select Aileron. Set Switch: Switch F
Move Switch F to the O position > Set High Rate %: 100 / 100; Expo %: 35 / 35
Move Switch F to the 1 position > Set High Rate %: 100 / 100; Expo %: 35 / 35
Move Switch F to the 2 position > Set Low Rate %: 75 / 75; Expo %: 35 / 35
11. Tap on the pull down tab at Channel and select Elevator. Set Switch: Switch F
Move Switch F to the O position > Set High Rate %: 100 / 100; Expo %: 35 / 35
Move Switch F to the 1 position > Set High Rate %: 100 / 100; Expo %: 35 / 35
Move Switch F to the 2 position > Set Low Rate %: 75 / 75; Expo %: 35 / 35
12. Tap on the pull down tab at Channel and select Rudder. Set Switch: Switch F
Move Switch F to the O position > Set High Rate %: 100 / 100; Expo %: 45 / 45
Move Switch F to the 1 position > Set High Rate %: 100 / 100; Expo %: 45 / 45
Move Switch F to the 2 position > Set Low Rate %: 75 / 75; Expo %: 45 / 45
13. Tap on the arrow in the upper left corner to return to the Model Adjust menu.
www.modellmarkt24.ch
3
4
5
50
75
100
3
4
5
50
75
100
7
EN
